YANMAR 4LHA-STP (Z) Marine Engine
YANMAR 4LHA-STP (Z) Marine Engine
Specifications
Rated output177 kW / 240 mhp
Rated Speed3300 rpm
Displacement3.455 L / 211 cu. in
No. of cylinders4 cylinders
Cylinder Bore x Stroke100 mm x 110 mm / 3.94 in x 4.33 in
Combustion systemDirect Injection, In-line Pump
AspirationTurbocharged & Intercooled
Alternator12V – 80A
Dry weight without gear365 kg / 805 lbs
Dimensions1131 mm x 719 mm x 811 mm
ControlsMechanical
CertificationsRCD 1 IMO Tier 2 BSO II EMC SOLAS
NOTE:
1 kW = 1.3596 mhp = 1.34102 bhp
Fuel condition: density at 15°C = 0.842 g/cm³
Technical data is according to (ISO 8665) / (ISO 3046)
Fuel temperature 25°C at the inlet of the fuel injection pump (ISO 3046)
Dimensions include KMH50A gearbox and L-type elbow
(Dimensions may vary with other gears/elbow)
Description
YANMAR 4LHA-STP (Z) Marine Engine
Performance Curves
Technical Drawings
