Specifications
Rated output41.9 kW / 57 mhp
Rated Speed3000 rpm
Displacement2.19 L / 134 cu. in
No. of cylinders4 cylinders
Cylinder Bore x Stroke88 mm x 90 mm / 3.46 in x 3.54 in
Combustion systemDirect Injection, Bosch Common Rail System
AspirationNatural
Alternator12V – 125A
Dry weight without gear220 kg / 485 lbs
Dimensions870 mm x 589 mm x 627 mm
ControlsMechanical (optional – VC10 system)
CertificationsRCD 2 EPA Tier 3 EPA Tier 3C BSO II EMC SOLAS
NOTE:
1 kW = 1.3596 mhp = 1.34102 bhp
Fuel condition: density at 15°C = 0.842 g/cm³
Technical data is according to (ISO 8665) / (ISO 3046)
Fuel temperature 40°C at the inlet of the fuel injection pump (ISO 8665)
Length includes KM35P marine gear
(Dimensions may vary with other gears/elbow)
HVO-approved engineDescription
Buy YANMAR 4JH57 Marine Engine
Performance Curves
Technical Drawings
Packages
Standard Engine Package
Optional Accessories
- High-riser mixing elbow [instead of L-elbow]
- Secondary alternator 12V – 125A or 24V – 60A
- C35 panel
- Extension harness [3m, 5m, 10m]
- Second station
- TFX Sidemount control head
- VC10 Vessel Control System
- NMEA2000 Engine monitoring system
- Semi 2-pole
- SOLAS including Certificate [factory fit only]
- Hot water kit with cocks
- Extension saildrive leg [75 mm]
- Propeller cone nut kit SD60
- On-board spare parts kit
